Electrical:

1. Voltage rating: 125 vac RMS
2. Current rating: 1.5 amp
3. Contact resistance: 100 milliohms max
4. Insulation resistance: 1000 megohms min @ 500 vdc
5. Dielectric strength: 750 vac RMS 60Hz, 1min

Environmental:
1. Storage: -40° To +85°
2. Operation: 0° To 70°

Mechanical:

1. Housing material: PC UL94v-0
2. Insert material: Flame retardancy ABS UL94v-0
3. PCB material: Fr-4 thickness: 1.6mm
4. Contact material: Phosphor bronze stamp pin t=0.35mm
5. Idc contact material: Phosphor bronze t=0.50mm with nickel plating
6. Wire: Awg 24-26

SMITON.

Shenzhen S-Miton Technology Co., Ltd.. is located in Guangdong Province, China.Founded in 2001, we are

specialized in the R&D and manufacture of wires, cables and telephone accessories. Telephone cable,

 Fiber Optic Cable , Patch Cord Cable,HDMI & VGA cable, Lan cable UTP/FTP/S-FTP Category 5E & Category 6, .....
Our company has gained the UL, CE and RoHS certification. Moreover, we have a group of experienced technicians

 and quality administrators to ensure quality.
